Filling and Packing Machines / Metal Tanks / Water Treatment

GPK 60
GPK 120
GPK 140

Vertical Sachet Machines

Filling Heads

• Application

Large sachets with 3 or 4 sided seal.

• Function

Intermittent horizontal form, fill & seal.

• Seal Type

Constant heat.

• Packaging Material

Single reel, heat sealable packaging material with either registration mark or continuous print.

• Reel Dimensions

Diameter 400mm [max], width 400mm [max] Core diameter 65mm – 75mm

• Filling Options

Liquids, powders, granules, tablets.

• Filling Head Options

Auger filler, Piston filler, Gear pump,Tablet filling head

• Sachet Size

70mm [W] x 100mm [L] min 140mm [W] x 200mm [L] max

• Filling Weight

250g/300cc

• Speed

70 Sachets/minute [max], depending on sachet size, filling weight and packaging material.

• Machine Dimensions

2600mm [W] x 1050mm [L] x 1750mm [H]

• Machine Weight

950kg [ approx]

• Electrical Requirements

380V 3ø, 15A

• Pneumatic Requirements

Depending on filling head option and machine extras

• Noise Level Below 70dB

• Extras

Vibrator, bottom seal, pneumatic notching, level control, batch counter, outfeed conveyor, wiring for multiple filling heads and Markem thermal transfer date coder.

Liquid and Granual Fill
